  • 0602 Mini SMD LED Ice Blue

0602 Mini SMD LED Ice Blue

  • Product Item : R0602IBNB-XG03
  • Category: 0602 SMD LED
  • Package: SMT package 0602
  • Color: Ice Blue
  • Intensity:300~500mcd
  • Radiation: 150° (horizontal), 130° (vertical)
  • INQUIRY   EMAIL

Descriptions
SMD LED lamps from ArkTech are available in miniature sizes and special configurations for automated PC board assembly and space-sensitive applications. 0602 SMD LED are suitable for use in a wide variety of electronic equipment, including cordless and cellular phones, notebook computers, network systems, home appliances, and indoor signboard applications.


Part No. Color Wavelength/CT Lens type Intensity View Angle VF(V) IF(mA)
R0602IBNB-XG03
Ice Blue 460~470nm
Water Clear
300~500mcd
120°
2.8~3.4V 20mA


Features
1.6 mm x 0.6 mm SMD LED, 1.0 mm thickness
SMT package, colorless diffused resin
Low power consumption
Wide viewing angle.
Package: 4000 pcs / reel
MSL (Moisture Sensitivity Level): 3
Compatible with automatic placement equipment.
Compatible with reflow solder process.
ESD: 8 kV acc. to ANSI/ESDA/JEDEC JS-001 (HBM, Class 3B)
Halogen-free
RoHS compliant

APPLICATIONS
Backlight Status indicator for keypad and keyboard.

Home and smart appliances
Wearable and portable devices
Healthcare applications
ATTENTION
Observe precautions for handling electrostatic discharge sensitive devices. Electrostatic discharge and power surge could damage the LEDs.
It is recommended to use a wrist band or anti-electrostatic glove when handling the LEDs. All devices, equipments and machineries must be electrically grounded.
