5mm Infrared Emitting Diode Straw Hat

Part No.

Wavelength
λd (nm)

Radiation Intensity Ie

(mW/sr)

Viewing Angle

(deg.)

Typ. Forward Voltage VF

(V)

Forward Current
IF (mA)

LID5G03L1

850nm

Min. 4
Typ. 8

55°

1.4@IF = 20mA
1.5@IF =100mA

1.2mA

FEATURES
High-brightness
High reliability
Low-voltage characteristics
Narrow view angle
Pb FREE Products
RoHS Compliant

Note:
All Dimensions are in millimeters
Tolerance is ±0.25mm(0.010 ") Unless otherwise specified
Protruded resin under flange is 1.5mm(0.059 ") max

All design applications should refer to ArkTech through hole LED application notes.
