  • Digit display,0.8 inch, one digit

Digit display,0.8 inch, one digit


Features

- High intensity and reliability

-High brightness, Low power requirement

-IC compatible , Easy assembly

- RoHS compliant, Pb free

-Wide View Angle

-Standard: black surface, white segment

Part No. Color Wavelength/CT Polarity Size Digits VF(V) IF(mA)
R11083A
Red 620~630nm CA/CC 0.8" One 1.9~2.2V 20mA
Y11083A
Yellow 585~595nm CA/CC
0.8"
One
1.9~2.2V
20mA
B11083A
Blue 455~465nm
CA/CC
0.8"
One
2.8~3.4V 20mA
YG11083A
Yellowlish Green 565~575nm
CA/CC
0.8"
One
1.9~2.2V
20mA
PG11083A
Pure Green 520~525nm
CA/CC
0.8" One
2.8~3.4V
20mA
O11083A
Orange 600~610nm
CA/CC
0.8"
One
1.9~2.2V
20mA
W11083A
White 1800~20000K CA/CC
0.8" One
2.8~3.4V
20mA

Parameters

(1) Digit: single.
(2) The height of glow surface:0.8 inches.
(3) Total PINs:10pins.
(4) Public feet:3 8.
(5) Dimensions:20.0x27.7x8.0mm.
(6) Glow color:bright red/yellow/yellow/amber/blue/white/pure green.
(7) Reflected cavity surface color:black/gray.
(8) Epoxy color:white/red/green/blue/yellow.
(9) Polarity:common anode/Common Cathode.
(10) Using temperature range:-20 to 80 degrees Celsius.

If you need other 7 segment LED display, please check out our other products.

For design applications please refer to ArkTech LED display application notes.
